Controlador inteligente del sistema LNL-X3300

• DHCP and fixed IP addressing supported
• DNS device naming through DHCP extended commands
• Optional Secondary NIC, USB port (2.0) with optional adapter
• 15 MB of available on-board, non-volatile flash memory
• Battery-back, non-volatile storage of 50,000 events
• Configurable option for Data at Rest encryption
• Firmware stored in flash memory, background download of firmware updates supported
• 12 or 24 VDC input power
• Supports up to 16 badge formats
• Biometric template storage support
• Up to 32,000 access level permissions
• 255 holidays with grouping
• 255 timezones, each with 6 intervals
• Elevator control support for up to 128 floors
• Supports up to 9-digit user PIN codes
• Status LEDs for heartbeat & battery status, upstream and downstream communication, and memory write status
• Two dedicated inputs for tamper and power failure status
• Advanced Encryption Standard (AES) 256-bit algorithm for communication to Lenel Series 3 reader and I/O modules; AES 128 bit encryption with Lenel Series 2 reader and I/O modules
• AES128 or TLS 1.2 (with AES256 support) communication to OnGuard
• RNDIS Support to allow USB connection to display controller web configuration pages

--------------------------------------------------------------------------
