Controlador inteligente de doble lector LNL-X2220

INFORMACIÓN

Controller Functionality

• DNS device naming through DHCP extended commands
• 6 MB of available on-board, non-volatile flash memory
• Battery-backed, non-volatile storage of 50,000 events
• Configurable option for Data at Rest encryption
• Firmware stored in flash memory, background download of firmware updates supported
• Supports up to sixteen badge formats
• Biometric template storage support for OSDP™ Biometric and legacy Bioscrypt® readers
• Optional Secondary NIC, USB port (2.0) with optional adapter
• Enhanced anti-passback capabilities
• Up to 32,000 access level permissions
• Elevator control support for up to 128 floors
• Individual extended held open and strike times
• Two dedicated inputs for tamper and power failure status
• Advanced Encryption Standard (AES) 256-bit algorithm for communications to Lenel Series 3 reader and I/O modules; AES 128 bit encryption to Lenel Series 2 reader and I/O modules
• AES128 or TLS 1.2 (with AES256 support) communication to OnGuard
• RNDIS support enables USB connection to display controller web configuration pages

Reader Interface Functionality

• Supports Data 1/Data0, Clock/Data, Supervised and Unsupervised F2F and OSDP-compatible RS-485 readers and keypads
• Support for OSDP Biometric template transfer and Secure Channel Encryption
• Door contact supervision (open/closed) and REX push-button monitor for each door

--------------------------------------------------------------------------
